PowerShell Script to Configure an NSX-T Load Balancer for the vRealize Suite & Workspace ONE Access

As part of my role in the VMware Hyper-converged Business Unit (HCIBU) I spend a lot of time working with new product versions testing integrations for next-gen VMware Validated Designs and Cloud Foundation. A lot of my focus is on Cloud Operations and Automation (vROPs, vRLI, vRA etc) and consequently I regularly need to deploy environments to perform integration testing. I will typically leverage existing automation where possible and tend to create my own when i find gaps. Once such gap was the ability to use PowerShell to interact with the NSX-T API. For anyone who is familiar with setting up a load balancer for the vRealize Suite in NSX-T – there are a lot of manual clicks required. So i set about creating some PowerShell functions to make it a little less tedious and to speed up getting my environments setup so i could get to the testing faster.

There is comprehensive NSX-T API documentation posted on code.vmware .com that I used to decipher the various API endpoints required to complete the various tasks:

  • Create the Load Balancer
  • Create the Service Monitors
  • Create the Application Profiles
  • Create the Server Pools
  • Create the Virtual Servers

The result is a PowerShell module with a function for each of the above and a corresponding JSON file that is read in for the settings for each function. I have included a sample JSON file to get you started. Just substitute your values.

Note: You must have a Tier-1 & associated segments created. (I’ll add that functionality when i get a chance!)

PowerShell Module, Sample JSON & Script are posted to Github here

Create a multi pNIC VMware Cloud Foundation NSX-V Workload Domain with PowerVCF

Hopefully by now you’ve seen my earlier posts about the new PowerShell module for the VMware Cloud Foundation API. If not i’d suggest reviewing these before reading on

With the release of VMware Cloud Foundation 3.9.1 it is now supported, via the API only, to use more than 2 physical NICs (pNICs) per host. In fact the API now supports up to three vSphere Distributed switches and six physical NICs, providing more flexibility to support high performance use cases and physical traffic separation.

There is a tech note that goes into more detail on the use cases for more than 2 pNICs and it also shows how this works using PostMan but we can also achieve this using PowerVCF.

The workflow using PowerVCF is the same as my earlier example for creating a workload domain. The only difference is the content in the JSON file.

Note: There is a validation API to validate the JSON you are passing before making the submission. PowerVCF dynamically formats the validation JSON as the formatting is slightly different to what you submit to create the workload domain.

To get you started there is a sample JSON file with the required formatting. Here is a snapshot of what it looks like

{
  "domainName": "PowerVCF",
  "vcenterSpec": {
    "name": "sfo01w01vc01",
    "networkDetailsSpec": {
       "ipAddress": "172.16.225.64",
       "dnsName": "sfo01w01vc01.sfo01.rainpole.local",
       "gateway": "172.16.225.1",
       "subnetMask": "255.255.255.0"
     },
     "rootPassword": "VMw@re1!",
     "datacenterName": "PowerVCF-DC"
   },
   "computeSpec": {
      "clusterSpecs": [ {
          "name": "Cluster1",
          "hostSpecs": [ {
              "id": "d0693b58-4012-4387-92ed-721cfa709e44",
              "license":"AAAAA-AAAAA-AAAAA-AAAAA-AAAAA",
              "hostNetworkSpec": {
                 "vmNics": [ {
                     "id": "vmnic0",
                     "vdsName": "SDDC-Dswitch-Private1"
                  }, {
                     "id": "vmnic1",
                     "vdsName": "SDDC-Dswitch-Private1"
                  }, {
                     "id": "vmnic2",
                     "vdsName": "SDDC-Dswitch-Private2"
                  }, {
                     "id": "vmnic3",
                     "vdsName": "SDDC-Dswitch-Private2"
                  } ]
               }
            }, {
              "id": "7006bec4-fccb-49a0-bff6-fd56c807d26a",
              "license":"AAAAA-AAAAA-AAAAA-AAAAA-AAAAA",
              "hostNetworkSpec": {
                 "vmNics": [ {
                     "id": "vmnic0",
                     "vdsName": "SDDC-Dswitch-Private1"
                  }, {
                     "id": "vmnic1",
                     "vdsName": "SDDC-Dswitch-Private1"
                  }, {
                     "id": "vmnic2",
                     "vdsName": "SDDC-Dswitch-Private2"
                  }, {
                     "id": "vmnic3",
                     "vdsName": "SDDC-Dswitch-Private2"
                  } ]
               }
            }, {
              "id": "cc257a80-e179-4297-bf7e-179a0944bbab",
              "license":"AAAAA-AAAAA-AAAAA-AAAAA-AAAAA",
              "hostNetworkSpec": {
                 "vmNics": [ {
                     "id": "vmnic0",
                     "vdsName": "SDDC-Dswitch-Private1"
                  }, {
                     "id": "vmnic1",
                     "vdsName": "SDDC-Dswitch-Private1"
                  }, {
                     "id": "vmnic2",
                     "vdsName": "SDDC-Dswitch-Private2"
                  }, {
                     "id": "vmnic3",
                     "vdsName": "SDDC-Dswitch-Private2"
                  } ]
               }
           } ],
    "datastoreSpec": {
        "vsanDatastoreSpec": {
            "failuresToTolerate": 1,
            "licenseKey": "BBBBB-BBBBB-BBBBB-BBBBB-BBBBB",
            "datastoreName": "vSanDatastore"
         }
     },
     "networkSpec": {
         "vdsSpecs": [ {
             "name": "SDDC-Dswitch-Private1",
             "portGroupSpecs": [ {
                 "name": "SDDC-DPortGroup-Mgmt",
                 "transportType": "MANAGEMENT"
             }, {
                 "name": "SDDC-DPortGroup-VSAN",
                 "transportType": "VSAN"
             }, {
                 "name": "SDDC-DPortGroup-vMotion",
                 "transportType": "VMOTION"
             } ]
          },
          {
             "name": "SDDC-Dswitch-Private2",
             "portGroupSpecs": [ {
                "name": "SDDC-DPortGroup-Public",
                "transportType": "PUBLIC"  } ]
           }
        ],
        "nsxClusterSpec": {
           "nsxVClusterSpec": {
              "vlanId": 2237,
              "vdsNameForVxlanConfig": "SDDC-Dswitch-Private1"
            }
          }
        }
      } ]
   },
  "nsxVSpec" : {
    "nsxManagerSpec" : {
      "name" : "sfo01w01nsx01",
      "networkDetailsSpec" : {
        "ipAddress" : "172.16.225.66",
        "dnsName" : "sfo01w01nsx01.sfo01.rainpole.local",
        "gateway" : "172.16.225.1",
        "subnetMask" : "255.255.255.0"
      }
    },
    "nsxVControllerSpec" : {
      "nsxControllerIps" : [ "172.16.225.121", "172.16.225.122", "172.16.225.123" ],
      "nsxControllerPassword" : "VMw@re123456!",
      "nsxControllerGateway" : "172.16.225.1",
      "nsxControllerSubnetMask" : "255.255.255.0"
    },
    "licenseKey" : "CCCCC-CCCCC-CCCCC-CCCCC-CCCCC",
    "nsxManagerAdminPassword" : "VMw@re1!",
    "nsxManagerEnablePassword" : "VMw@re1!"
  }
}

You can see that the magic happens in the hostNetworkSpec section where you map each vmnic to a vdsName

<p>"hostNetworkSpec": { "vmNics": [ { "id": "vmnic0", "vdsName": "SDDC-Dswitch-Private1" }, { "id": "vmnic1", "vdsName": "SDDC-Dswitch-Private1" }, { "id": "vmnic2", "vdsName": "SDDC-Dswitch-Private2" }, { "id": "vmnic3", "vdsName": "SDDC-Dswitch-Private2" } ] }</p>

So please try it out and let us know how it goes!

Introducing PowerVCF – A PowerShell Module for the VMware Cloud Foundation API

Its been a while since I’ve posted something so I thought it was about time! Since joining VMware a year ago I’ve been heads down drinking from the firehose, learning from a phenomenal team and generally keeping very busy. More recently I’ve been playing a lot with VMware Cloud Foundation (VCF). A recent release (3.8) introduced a public API and I started getting field questions on how to leverage it so I started digging. The API has been expanded in 3.9. It is based on the OpenAPI standard (formerly Swagger) and can be accessed through the developer center in the SDDC Manager UI or via code.vmware.com

Now I’m not a developer so I fell back on Postman to do some initial testing. I like Postman as it dumbs it down for us non-devs 🙂 but I wanted something a little easier to consume so i started a little side project called PowerVCF (hat-tip to the far superior PowerNSX, PowerVRA, PowerVRO)

Basically I wanted to provide a simple, efficient, PowerCLI style experience for consuming the VMware Cloud Foundation public API.

Solution?

I am delighted to unleash the first iteration of PowerVCF on the community! Creating this has been a great learning experience for me. In the process I’ve improved my PowerShell skills, learned Git, Markdown and have started looking into CI/CD workflows. It’s also my first submission to the PowerShell Gallery.

Reset/Unlock Photon OS root account

From time to time your root account can get locked from either entering the incorrect password or using some automation that uses the wrong password. Here are some quick steps.

Reboot the Photon Appliance

At the Photon OS logo screen press e to edit the grub menu

At the grub menu append the following to the end of the boot loader line to boot into single user mode

rw init=/bin/bash

Press F10 or CTRL+X to continue the boot process

At the prompt type the following to mount the root partition

mount -o remount,rw /

To reset the root password type passwd and enter the new password

If the root account was locked due to x number of failed logon attempts type to following to unlock it

/sbin/pam_tally2 -r -u root

Unmount the partition again

umount /

And reboot

reboot -f

Hopefully you should now be able to log in with your root account!

Verify NTP Configuration on a VMware Photon Appliance

Quick post with the commands required to verify NTP configuration on a VMware Photon OS Appliance

ssh to the appliance as root

To check if the NTP service is up and running you can run this command

systemctl status systemd-timesyncd

If its stopped run this command

systemctl start systemd-timesyncd

To configure NTP servers run the following

vi /etc/systemd/timesyncd.conf

Add timeservers under [Time]

Automate your VMware Validated Design NSX-V Distributed Firewall Configuration

A few weeks back I mentioned on twitter that i was working on automating the VMware Validated Design NSX-V Distributed Firewall Configuration in my lab. (I admit it took longer than i had planned!) Currently this is a manual post deployment step once VMware Cloud Builder has completed the deployment. This will likely be picked up by Cloud Builder in a future release but for now its a manual, and somewhat tedious, but required, step!

Full details on the manual steps required for this configuration can be found here. Please take the time to understand what these rules are doing before implementing them.

So in an effort to make this post configuration step a little less painful i set out to automate it. I’ve played with the NSX-V API in the past and found it much easier to interact with by using PowerNSX, rather than leveraging PostMan and the API directly. PowerNSX is the unofficial, official automation tool for NSX. Hats off to VMware engineers Nick Bradford, Dale Coghlan & Anthony Burke for creating and documenting this tool. Anthony also published a FREE book on Automating NSX for vSphere with PowerNSX. More on that here.

Disclaimer: This script is not officially supported by VMware. Use at your own risk & test in a development/lab environment before using in production.

I’ve posted the script to GitHub here as its a bit lengthy! There may be a more efficient way to do some parts of it and if anyone wants to contribute please feel free!

As with a lot of the scripts i create it is menu based and has 2 main options:

  1. Create DFW exclusions, IP Sets & Security Groups
  2. Create DFW Rules

The reason i split it into 2 distinct operations is to allow you to inspect the exclusion list, IP Sets & Security Groups before creating the firewall rules. This will ensure that you dont lock yourself out of vCenter by creating an incorrect rule.

Required Software

  • PowerCli
    • The script will check for PowerCli and if not found will attempt to install the latest version from the PowerShell Gallery
    • Currently tested on Windows only
    • If you dont have internet access you can manually install PowerCli by opening a PowerShell console as administrator and running:
    • Find-Module -Name VMware.PowerCLI | Install-Module
  • PowerNSX
    • The script will check for PowerNSX and if not found will attempt to install the latest version from the PowerShell Gallery
    • Currently tested on Windows only
    • If you dont have internet access you can manually install PowerNSX by opening a PowerShell console as administrator and running:
    • Find-Module -Name PowerNSX | Install-Module

Required Variables

Before you can run the script you need to edit the User Variables to provide the following:

  • Target vCenter details
    • Required to establish a PowerCli Connection with vCenter Server. This is used when updating the DFW exclusion list
  • Target NSX Manager details
    • Required to establish a connection with NSX manager to configure the DFW
  • IP Addresses for the various SDDC components

Hopefully you will find this useful!

VMware Validated Design – Automated Deployment with Cloud Builder – Part 6: Deploy The SDDC

This is part 6 of a series of posts on VMware Cloud Builder.

In this final post, now that we have passed all validation, we will run the SDDC deployment using VMware Cloud Builder.

Continue reading “VMware Validated Design – Automated Deployment with Cloud Builder – Part 6: Deploy The SDDC”

VMware Validated Design – Automated Deployment with Cloud Builder – Part 5: Cloud Builder Deployment & Environment Validation

This is part 5 of a series of posts on VMware Cloud Builder.

Hopefully you’re still with me!

In this post I will cover the deployment and initial configuration of the VMware Cloud Builder appliance, ingestion of the deployment parameters file, and environment validation.

Continue reading “VMware Validated Design – Automated Deployment with Cloud Builder – Part 5: Cloud Builder Deployment & Environment Validation”

VMware Validated Design – Automated Deployment with Cloud Builder – Part 4: Generating SSL Certificates

This is part 4 of a series of posts on VMware Cloud Builder.

In this post I will cover generating the required SSL certificates for deploying this VMware Validated Design with VMware Cloud Builder.

Friendly warning: This is a long post so maybe get a coffee before reading!

Continue reading “VMware Validated Design – Automated Deployment with Cloud Builder – Part 4: Generating SSL Certificates”

VMware Validated Design – Automated Deployment with Cloud Builder – Part 3: Deployment Parameters File

This is part 3 of a series of posts on VMware Cloud Builder.

In this post I will cover the deployment parameters file.

Continue reading “VMware Validated Design – Automated Deployment with Cloud Builder – Part 3: Deployment Parameters File”
